Interlogix Simon XT Installation Guide

Menu Description
---- Last Temp. Read
For troubleshooting only. Shows how many unsuccessful
attempts were made by the LTE module at trying to
communicate with the Z-Wave thermostat. A low number
of 0 or 1 is normal.
-- Request Weather Update
Press OK if the weather forecast is not showing on the
touch screen (2WTTS).
[1] All Image Sensor menus are only available when an Image Sensor daughterboard has been connected to the
module or an Image Sensor radio is built-in. An Image Sensor daughterboard is required to enable Image Sensor
functionality. For information on how to determine if the Image Sensor radio is built into the module, see Built-In Radios.
An interactive Alarm.com account with an Image Sensor service package is required for image capabilities and features.
[2] Refer to the emPower installation instructions and guides on the Partner Portal for more information on Z-Wave
enrollment and troubleshooting.
Contact information
For additional information and support on Alarm.com products and services, see www.alarm.com/dealer or contact
Alarm.com technical support at 1-866-834-0470.
Regulatory Information
Listings FCC ID: YL6-143450L, IC: 9111A-143450L
This device contains FCC ID: RI7LE910SV, IC: 5131A-LE910SV
Changes or modifications not expressly approved by Alarm.com can void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Simon_XT/Interlogix_Simon_XT_…
Updated: Tue, 31 Mar 2020 20:51:49 GMT
20

Interlogix Simon XT Specifications

Power

power requirements	6V nominal
standby current	30mA (10mA in PowerSave Mode)
peak current	1.7 A

Operating Environment

operating temperature	32 to 120°F (0 to 49°C)
storage temperature	-30 to 140°F (-34 to 60°C)
max. relative humidity	90% non-condensing

Dimensions

height	4 1/16 in.
width	1 7/8 in.
