PPAARRTTSS RREEFFEERREENNCCEE
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to
scale.
REF. NO.
DESCRIPTION
QTY.
SPARE PART NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
CLEANER TOP
SCREW
BUMPER
DEBRIS NET
CLEANER BASE
HOSE CLAMP
HOSE ADAPTOR (OPTIONAL)
HOSE A
HOSE B
HOSE C
HOSE D
HOSE ADAPTOR FOR SMALL AGP POOL (OPTIONAL)
DEAD WEIGHT BLOCK
10960
10858
10857
10855
10965
10272
10859
10850
10851
10852
10957
10910
11138
1
2
2
1
1
1
1
1
3
2
1
1
2
1
2
7
8
9
10
11
3
6
4
13
5
12
