SAVE THESE INSTRUCTIONS
Page 9
(100IO) AUTO CLEANER ENGLISH 7.5” X 10.3” PANTONE 295U 08/05/2008
English
OOPPEERRAATTIINNGG IINNSSTTRRUUCCTTIIOONNSS
1. The filter pump is an airtight system. In a counter-clockwise motion turn
the top air release valve 1 – 2 turns to open it.
2. When water starts flowing out of the air release valve hole, screw in the
air release valve back into the filter housing cover. Do not over tighten
the valve.
3. Connect the filter pump to the power outlet and turn ON the pump.
4. Hold the auto cleaner upside down below the water surface to jet out
the water. See Fig. 9. This will evacuate all the air in the hose and
auto cleaner, so the cleaner will sink to the bottom and keep the pool
clean.
5. The auto cleaner will change direction each time one of the bumpers
touches the pool sidewall.
OPERATING INSTRUCTIONS
9
