(110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/13/2022
110
GS
SAVE THESE INSTRUCTIONS
English
Page 12
CLEANING OR REPLACING FILTER CARTRIDGE
It is recommended that the filter cartridge be replaced at least every 2 weeks or as
needed. Regularly monitor the filter clogging level.
The filter pump is equipped with a filter gauge, which indicates when to
clean or replace the filter cartridge:
•
Green zone: the filter cartridge is clean, no need to clean or replace.
•
Yellow zone: the filter cartridge is dirty; it needs to be cleaned.
•
Red zone: the filter cartridge is excessively dirty; it shall be cleaned or
replaced.
NOTE:
To ensure a correct filter gauge reading, remove any accessories
(skimmer, lights, sprayer, auto cleaner, etc) from the filtration system inlet
and outlet line. See “Troubleshooting Guide” section for details.
When the pump is not running (stand by mode) or OFF, the filter gauge indicator is in the green
zone. You must activate the filter pump to see the last filter gauge indicator status.
The following steps provide instructions on how to clean or replace the filter cartridge.
1.
Make sure the filter pump is turned off, then disconnect the power cord from the electrical
outlet.
2
. Turn both plunger valve handles fully clockwise until they stop. This closes the valve,
prevents the water from flowing out of the pool.
3.
Gently turn the top air release valve once or twice in a counter-clockwise direction. The
housing cover can now be easily removed.
4.
In a counter-clockwise direction remove the filter housing collar
(1).
Place it in a safe
location.
5.
Remove the housing cover
(4).
6.
Remove the used filter cartridge and use a strong pressure garden hose to rinse it clean.
Replace with a new filter cartridge when it is discolored, deformed, has small holes and tears
or as needed.
7.
Examine the inside of the filter housing.
8.
If dirt or sediment is located on the bottom of the housing then:
A.
In a counter-clockwise motion gently unscrew and remove the sediment valve
(9)
located at the bottom of the housing. Place it in a safe place.
B.
With a bucket of water or a garden hose pour water into the housing flushing out the
sediment.
C.
Screw back the sediment valve
(9)
in a gentle clockwise motion. Do not over-tighten.
9.
Place a clean or new cartridge filter in the housing. Only use the original Intex cartridge for
replacement. See “Parts Reference” section for detail.
10.
Return the housing cover
(4)
to its position and in a clockwise direction rescrew the housing
collar
(1)
onto the filter housing.
11.
Turn both plunger valve handles fully counter-clockwise until they stop. This opens the
valve, allowing water to flow into the filter pump.
12.
When the trapped air has escaped through the air release valves gently retighten the valves
(2 & 7)
in a clockwise direction.
13.
Reconnect the power cord.
14.
Turn on the pump.
15.
Check the inlet and outlet openings regularly to ensure they are not obstructed thus
preventing a good filtration.
16.
The disposal of any used filter media should be in accordance with applicable local
regulation and legislation.
Filter gauge
