5.
Disconnectbatterycable(1).
6.Removerearwheelxingscrews.
7.Removerearwheels.
8.Removedriveunit.See4.10.1Replacingdriveunit,page
29.
9.Removescrews(1)onpowermodule(2).
•Rhino1:
Fig.4-7DS112KB02/DS162KD01
•Rhino2:
Fig.4-8DS120
Fig.4-9DS160
10.
Replacepowermodule(2).
11.Installpartsinreverseorder.
12.Loaddriveprogramontopowermodule.Seecontrols
softwaredescription.
13.Testallfunctions(trialrun).
4.5.6Setupsettings
Operatingconsole(LEDversion)
Arrangement
A
Statusdisplay
B
Switchingon/offcurvecontrol(reductionofspeed
whendrivinginacurve)
C
Hazardlights
D
Horn
E
Left-handdirectionindicator(switchesitselfoff
automaticallyafter30seconds)
F
Speedcontroldial
G
Right-handdirectionindicator(switchesitselfoff
automaticallyafter30seconds)
H
Lighting
I
Lowspeedmode
J
Drivelever
Statusdisplay
TheON/OFFdiode(1)isusedasafaultdisplay
(statusdisplay).Itwillashifthereisaproblem
withthescooter.Thenumberofashesindicates
thetypeoferror.Referto4.2.3Errorcodesand
diagnosticcodes,page9.
Batteryindicationgauge
Lowbatteryindication:Everytimethescooteris
activatedoratworkwhenbatterycapacityislower
than25%,theelectronicsystemwillbeepthree
times.
Overdischargeprotection:afteracertaindrivetime
onreservebatterypowertheelectronicsystem
switchesthedriveoffautomaticallyandbringsthe
scootertoastandstill.Ifyoudonotdriveyour
scooterforawhilethebatterieswill"recuperate"
andallowafurther,butshort,journey.However,
afteraverybriefjourneythebatteryreservesymbol
willilluminateagainandtheelectronicsystemwill
beepthreetimes.Thisprocedureleadstobattery
damageandshouldbeavoidedifpossible!
