1.Removerearshroud.See4.6.1Removingshroud,page
18.
2.
RemovefourcapsA.
3.LoosenandremovescrewsB.
4.Takeofffrontshroud.
5.Installpartsinreverseorder.
4.7Lightingunit
4.7.1Replacingheadlight
Youcanreplaceheadlightwithoutremovingthe
chassis.If,however,theworkingspaceistoosmall,
youcanremovethechassisasdescribedinchapter
4.8.4Replacingsteeringcolumn,page23
.
•Phillipsscrewdriver
1.Removeseat.
2.Removeshroud.
3.
DisconnectbatterycableA.
4.Removerearsteeringcolumnshroud.See4.8.4
Replacingsteeringcolumn,page23.
5.
RemovescrewAonheadlightunderfrontshroud.
6.DisconnectdirectionindicatorcableBatwiringharness
behindsteeringcolumnshroud.
7.
Removeheadlight.
8.Removescrews(1)onheadlightglass.
9.Removeheadlightglass.
10.Replacebulb(2)inheadlight.
11.Installpartsinreverseorder.
12.Testallfunctions.
4.7.2Replacingfrontdirectionindicators
•Phillipsscrewdriver
1.Removeseat.
2.Removeshroud.
3.
DisconnectbatterycableA.
4.
RemovedirectionindicatorscrewAonhousing.
5.DisconnectdirectionindicatorcableBfromwiring
harness.
1603798-B19
