Replacingsteeringcolumn
1.
RemovedriveleverscrewsC.
2.RemovedriveleverB.
3.LoosenandremovescrewsAonoperatingconsole.
4.Removeoperatingconsole.See4.5.1Replacing
operatingconsole,page11
.
5.
RemovescrewsAonrearsteeringcolumnshroud.
6.Removesteeringcolumnshroud.
7.Loosenscrewsonfrontbasketholder.
8.Removebasketholder .
9.Removespacerbushes.
10.Disconnectcablesfromwiringharness.
11.
RemovescrewsAonfrontsteeringcolumnshroud.
12.Removefrontsteeringcolumnshroud.
13.Loosenbrakecable.See4.9.1Replacinghandbrakes,
page26.
14.
Loosenandremovescrewatclamp(1).
15.Loosenandremovexingboltforsteeringcolumn.
16.Pullsteeringcolumnoutupwards.
17.Installpartsinreverseorder.
Tightenscrew(1)to13Nm.
18.Applybrake,tightenaxleboltsatsametime.
19.Testallfunctions(trialrun).
4.8.5Replacingfrontwheelsuspension4–wheel
CAUTION!
Riskofaccident
Accidentalrollingcanleadtoaccidents.
–Securemobilitydeviceagainstrollingaway.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
•10mmwrench
•13mmwrench
•17mmwrench
•19mmwrench
•32mmwrench
•Phillipsscrewdriver
•Supportingwoodenblock
24
1603798-B
