Invacare Leo User Manual

53
8.6.2 Removing the rollator bracket
• Loosen the screws (1).
• Pull the rollator bracket out of the fixtures.
8.6.3 Positioning the rear reflector
CAUTION! Risk of accident due to poor visibility.
If you wish to use your wheelchair on public roads and a rear reflector is required by
national legislation, then the rollator bracket may not cover the rear reflector.
• Make sure that the rear reflector is mounted in such a way that a sufficient amount of the
reflective area is visible.

Invacare Leo Specifications

General

Maximum Speed	8 km/h
Weight Capacity	136 kg
Ground Clearance	7 cm
Battery	2 x 12V
Seat Width	47 cm
Seat Depth	41 cm (16.1 inches)
Maximum Safe Slope	10 degrees
Turning Radius	43.3 inches (110 cm)
