77
12 Dismantling the Scooter for transport
Please proceed as follows to dismantle the Scooter for transport:
• Remove the seat
• Take out batteries
• Remove the drive unit
Please proceed in reverse order to reassemble the Scooter.
12.1 Removing the seat
The lever for releasing the seat so that the seat can be rotated
and removed is located on the left under the seat (1).
• Press the lever forwards to disengage the seat.
• Turn the seat to the side.
• To remove the seat, hold it firmly by the backrest and the
front edge and pull it upwards.
