Invacare Leo User Manual

62
• Loosen the blue cable on the negative battery
terminal with the open-ended spanner, and remove
the cable.
• Loosen the red cable battery clamp on the positive
battery terminal with the open-ended spanner, and
remove the cable.
• Repeat the procedure for the other battery
NOTE:
Replacing new batteries takes place in reverse order.

Invacare Leo Specifications

General

Maximum Speed	8 km/h
Weight Capacity	136 kg
Ground Clearance	7 cm
Battery	2 x 12V
Seat Width	47 cm
Seat Depth	41 cm (16.1 inches)
Maximum Safe Slope	10 degrees
Turning Radius	43.3 inches (110 cm)
