INVT GD20-2R2G-S2 User Manual

Goodrive20 inverters Function Parameters
54
Function
code
Name Detailed instruction of parameters
Default
value
Modify
setting of
the upper limit
of AI3
The setting range of P05.46:P05.44~10.00V
The setting range of P05.48:0.000s~10.000s
P05.48
AI3 input filter
time
0.100s
○
P05.50
Lower limit
frequency of
HDI
0.000kHz~P05.52
0.000
kHz
○
P05.51
Corresponding
setting of HDI
low frequency
setting
-100.0%~100.0%
0.0%
○
P05.52
Upper limit
frequency of
HDI
P05.50~50.000kHz
50.000
kHz
○
P05.53
Corresponding
setting of upper
limit frequency
of HDI
-100.0%~100.0%
100.0%
○
P05.54
HDI frequency
input filter time
0.000s~10.000s
0.100s
○
P06 Group Output terminals
P06.01
Y1 output
selection
0:Invalid
1:In operation
2:Forward rotation operation
3:Reverse rotation operation
4: Jogging operation
5:The inverter fault
6:Frequency degree test FDT1
7:Frequency degree test FDT2
8:Frequency arrival
9:Zero speed running
10:Upper limit frequency arrival
11:Lower limit frequency arrival
12:Ready for operation
13:Pre-magnetizing
14:Overload pre-alarm
15: Underload pre-alarm
16:Completion of simple PLC stage
0
P06.03
Relay RO1
output
selection
1 ○
P06.04
Relay RO2
output
selection
5 ○
