TROUBLESHOOTING

183

2. UNSTABLE IDLING

Checkpoint Trouble Cause Countermeasure

Valve clearance

Compression pressure

Valve clearance improperly

adjusted

Adjust the valve clearance

Blown out cylinder head gasket

Worn cylinder liner

Piston ring sticking or broken

Improper seating between the

valve and the valve seat

Replace the related parts

NG NG

Continued from the previous page
