JACOBSEN G-PLEX III Series: DN & DP
SAFETY AND OPERATORS MANUAL
10.7 Tires
Keep tires properly inflated to prolong tire life. Check
inflation pressure while the tires are cool.““Use an
accurate, low pressure tire gauge.
Keep tires inflated to the air pressure specified
below.
20 x 10 - 10 Turf Tires 9 psi (0.62 bar)
10.8 ENGINE ACCESS
The rear section of the unit can be raised for better
access to the engine. Loosen the two handknobs
above the rear fork. Raise the fuel tank frame.
Support it by pivoting the rod beneath the fuel tank
down and securing it in the cup next to the fork pivot
(See Fig. 10.9).
Figure 10.8
Rear Section of Unit Raised
Caution must be used when inflating a
low pressure tire to the recommended
pressure. Check pressure with alow
pressure tire gauge befor connecting an
air hose to a partly inflated tire.
Due to the low air volume requirements
of a small tire, over inflation may be
reached in a matter of a few seconds,
which could cause the tire to explode.
CAUTION
DO NOT remove the fuel tank cap while
the tank is in the raised position.
WARNING
10 LUBRICATION & MAINTENANCE
