Jacobsen G-Plex III Safety And Operators Manual

GB-30
JACOBSEN G-PLEX III Series: DN & DP
SAFETY AND OPERATORS MANUAL
GB
10.9 ENGINE OIL LEVEL - GASOLINE
Damage to engines due to improper maintenance or
use of incorrect oil quality and/or viscosity is not
covered by the engine warranty (refer to the engine
operator's manual for crankcase capacity and
recommended oil grade and weight).
Unit must be on a level surface to obtain an
accurate oil level reading.
The oil level must be kept between the two marks on
the dipstick.
NOTE: DO NOT overfill. Engine overheating
and damage may result.
Figure 10.9
1. Oil Filler Port
2. Dipstick“
10 LUBRICATION & MAINTENANCE
10.9.1ENGINE OIL LEVEL - DIESEL
Damage to engines due to improper maintenance or
use of incorrect oil quality and/or viscosity is not
covered by the engine warranty (refer to the engine
operator’s manual for crankcase capacity and
recommended oil grade and weight).
Unit must be on a level surface to obtain an
accurate oil level reading.
The oil level must be kept between the two marks
on the dipstick.
NOTICE
• DO NOT overfill. Engine overheating and
damage may result.
• DO NOT use a wrench when installing the
filter, use hand pressure ONLY.
ENGINE OIL FILTER
When replacing the oil filter, apply a light film of
clean oil to the rubber seal. screw filter on until the
seal contacts the crankcase, then tighten 1/2 turn
more.
1
Figure 10.9.1
1. Dipstick
1
Figure 10.9.2
1. Oil Filler Port
