36
In the follwing menu item and the
intensity of red, green, blue and white can be adjusted. Change the value by means of
keys "UP" and "DOWN". The light beam will be altered according to the received input.
Pay attention, that one colour value stays at 100%. Otherwise the brightness of the unit
will be reduced. The intensity of the fixture can be adjusted from 0% -100% with
There is no pan & tilt readjustment during this process.
Setting the fixture back to factory defaults will not effect the white balance. (See chapter
3.2). The white balance influences the function colour wheel and RGBW colour mixing.
So for instance if one of the RGBW channels has been reduced significantly the colours
of the colourwheel will appear different compared to standard factory settings.
SKAL RED, SKAL GREEN, SKAL BLUE SKAL WHITE
SKAL
ALL.
FINE ADJUST - zoom adjustment
The zoom effect in all A12 is calibrated at the factory. But if necessary it is possible to fine-
tune the zoom using the command.ZOOM OFS
RECEIVESOFT
Use the command to prepare the A12 for a software upload. See 6.3
Software update and the uploader device documentation.
RECEIVE SOFT
6.2 Cleaning the fixture
To ensure a long and satisfying performance of the fixture, check function of the fans in
the head and in the base from time to time. Most important: make sure that there is no
dust or fluff covering the air inlets. To clean the fixture open fan filter lid and the baseplate.
If the air filter in the head is full of dust, clean or replace it (spare part no. JBK0088). Use a
brush and a vacuum cleaner to remove dust and fluff. Don´t damage or bend any parts.
Incompetend performace of the maintenance will invalidate the warranty claims. Consult
qualified service personnel.
WARNING:
ATTENTION:
Disconnect fixture from mains, and allow unit to cool
down for at least 10 minutes!
With direct view on the beam source use a welding goggle of reduction 4-5!
Débranchez l'appareil du secteur et le laissé refroidir au
moins 10minutes! Lors d'un regard direct dans la source lumineuse il est
fortement recommandé de porter une lunettes de soudeur équipée de
verres à vision atténué degré 4-5!
!
WARNING: A12 lights up immediately!
ATTENTION: A12 s'allume immédiatement sur fond blanc!
!
To individually adjust the brightness of the red, green and blue LEDs select the menu item
. Enter the FINE ADJUST menu by pressing "ENTER" (keep
pressed) and press "ESC" additionally.
SERVICE, FINE ADJUST
