JBL ESC 360 Service Manual

C24 C25 2 CHIP CAP 0.0068 uF 50V 10% PYL456470-6820
C77 C78 2 COND ELECT 10uF 25V 20% PRE039550-1000
C79 1 COND ELECT 1uF 50V 20% PRE039570-1090
C76 1 COND ELECT 2.2 uF 50V 20% PRE039570-2290
C42 C43 C44 C45 C46 5 CHIP CAP 220 pF 50V 5% PYL410370-2210
C47 C48 C49 C50 C51 C52 6 CHIP CAP 330 pF 50V 5% PYL410370-3310
C61 1 CHIP CAP 470 pF 50V 5% PYL410370-4710
C1 C2 C22 C3 C4 C5 C56 C57 C58 C59 C60 16 CHIP CAP 0.1 uF 50V 5% PYL456370-1040
C67 C68 C69 C70 C71
C80 1 CHIP CAP 0.015 uF 50V 5% PYL456370-1530
C74 1 CHIP CAP 0.022 uF 50V 5% PYL456370-2230
C32 C34 C35 C38 C39 5 CHIP CAP 0.0047 uF 50V 5% PYL456370-4720
C75 1 CHIP CAP 0.22 uF 50V 5% PYL456370-2240
C73 1 CHIP CAP 0.082uF 50V 5% PYL456370-8230
C84 1 COND ELECT 470uF 10V 20% PRE039530-4710
C26 C27 C28 C29 C30 C31 6 COND ELECT 47uF 10V 20% PRE039530-4700
C10 C11 C12 C13 C14 19 COND ELECT 100uF 16V 20% PRE039540-1010
C15 C16 C17 C18 C19
C20 C21 C53 C54 C55 C6 C7 C8 C9
R99 1 CHIP RES 2 OHM 1/10W 5% QCF015020-2090
R98 1 CHIP RES 43K OHM 1/10W 5% 0805 SMT TYPE QCF015020-4330
RP1 1 RES ARRAY 10k X 4 QVP085090-1030
R94 1 CHIP RES. 33K OHM 1/10W 5% QCF015020-3330
R101 R123 2 CHIP RES. 0 OHM JUMP WIRE QCF015020-0000
R106 R68 R69 R97 4 CHIP RES. 10 OHM 1/10W 5% QCF015020-1000
R10 R11 R12 R124 R13 18 CHIP RES. 100 OHM 1/10W 5% QCF015020-1010
R14 R15 R16 R17 R18 R19 R3 R4 R5 R6 R7
R8 R9
R110 R114 R115 R120 R132 R40 R52 R53 14 CHIP RES. 1K OHM 1/10W 5% QCF015020-1020
R70 R71 R72 R73 R74 R75
R105 R125 R126 R127 30 CHIP RES. 10K OHM 1/10W 5% QCF015020-1030
R131 R23 R24 R25 R30
R31 R34 R35 R36 R37
R38 R39 R41 R42 R43
R44 R46 R47 R48 R49
R50 R51 R54 R55 R56 R61
R93 R95 2 CHIP RES. 100K OHM 1/10W 5% QCF015020-1040
R1 R2 R82 R83 R84 R85 R86 R87 8 CHIP RES. 18K OHM 1/10W 5% QCF015020-1830
R103 R128 R26 R28 4 CHIP RES. 2.2K OHM 1/10W 5% QCF015020-2220
R112 R113 R117 R118 8 CHIP RES. 22K OHM 1/10W 5% QCF015020-2230
R129 R130 R133 R134
R88 R89 R90 R91 R92 R96 6 CHIP RES. 2.7K OHM 1/10W 5% QCF015020-2720
R100 R135 2 CHIP RES. 33 OHM 1/10W 5% QCF015020-3300
R62 R63 R64 R65 4 CHIP RES. 330 OHM 1/10W 5% QCF015020-3310
R107 R109 R111 R116 R119 R121 R27 R29 8 CHIP RES. 390 OHM 1/10W 5% QCF015020-3910
R108 1 CHIP RES. 470 OHM 1/10W 5% QCF015020-4710
R76 R77 R78 R79 R80 R81 6 CHIP RES. 4.7K OHM 1/10W 5% QCF015020-4720
R66 1 CHIP RES. 75 OHM 1/10W 5% QCF015020-7500
R20 R21 R32 R33 R45 R57 R58 7 CHIP RES. 7.5K OHM 1/10W 5% QCF015020-7520
Installation Point Qty. Description Material No.
1 CARTON L439xW439xH596mm ICC200001-0001
1 OWN MANUAL 148x210mm missing part number
1 SAFETY MANUAL L210xH297mm YOM100183-1001
1 SPK DRIVER 6.5" 4OHM 60W woofer FSA226061-1401
1 LINE CORD 2P 1980mm BLK VDE VPE003012-0020
1 CONTROL KNOB W/SPRAY MA4810 BPK005031-0000
1 SW ROCKER 5A AC 250V TV-5 MSW008004-0010
1 COND SAFETY X2 CAP 0.1uF 250V L=20mm TO POWER SW PLX2705G0-1040
4 FOOT METALLIC GREY-SILVER FOR FOOT BPE400005-0102
8 RUBBER FOOT NR3 BLACK 13.5xT2.0mm W/ADHE FOR FEET BRF200001-0001
1 POLYFOAM TOP 430x430xH100mm ITF200008-0001
1 POLYFOAM BOTTOM 430x430xH100mm ITF200009-0001
1 POLY BAG FOR RCA WIRE L240xW355mm IVA000001-0048
1 SOFT SHEETFOR AC CORD PLUG L100xW80mm IVH002001-0006
1 POLY BAG FOR MAIN UNIT L600xW850xD100mm IVA000001-0026
1 POLY BAG L240xW355mm IVA000001-0048
1 POLY BAG L80xW220mm IVA000001-0019
1 POLY BAG L240xW180mm IVA000001-0088
mech and accessories

JBL ESC 360 Specifications

General

Brand	JBL
Model	ESC 360
Category	Speaker System
Language	English
