JBL ESC 360 Service Manual

1 LOGO PLATE 22.5xW18mm JBL BPL000013-0001
1 PORT EDGE ABS W/SPRAY MA4810 BPR000020-0001
1 PORT (F) ABS MA4810 BPR000042-0BA0
1 BUSHING AC LINE BUSHING FOR BLACK FOR POWER WIRE DBU001002-0011
2 WIRE 22 GA 90mm RED 4-4 FOR POWER SW-2 VWR0333BB-0090
6 TUBING SRK DIA=6 L=20mm BLACK POWER SW TO POWER FUSE HOLDR DTB006000-0200
4 SCREW DRIVER TO WOOD BOX-4. T4.0x1.59PxL16mm HSP140091-3160
4 WASHER X'FORMER TO REAR PLT-4. OD8.5xID4.3xT0.6 mm HWT168543-1060
4 WASHER X'FORMER TO REAR PLT-4 OD16 ID4.5 T1.0 HWS11G045-1100
2 SPONGE L100xW30xT2mm IVE000085-0001
9 SCREW FOOT TO WOOD BOX-8,LOGO TO WOOD BOX-1. T3.5xP1.41x14mm HST140071-3140
4 RUBBER PAD DIA14.5mm ICH080007-0001
4 CU-SPACER M3.0xP0.5xL20mm HEXAGO HOT002006-0003
1 SPONGE T=2.0mm 26x78mm W/ADHESIVE IVE200010-0001
1 PCB BKT L SECC T=1.0mm GSE200020-0001
1 PCB BKT R SECC T=1.0mm GSE200021-0001
4 DIVIDER L250xW250mm EDGE SUPP. ICD000079-0001
1 SERIAL+BAR LABEL FOR SUB WOOFER. L42xW5mm MP (DVD UNIT) YLB118004-0001
1 SERIAL+BAR LABEL L85xW108mm MP(DVD UNIT) FOR GIFT BOX. YLB118002-0003
1 RUBBER PAD 23x8x12.8mm ICH080016-0001
1 SILICA GEL 3 g DOT040001-0003
2 WASHER FIB BETWEEN SCREW & AC3 PCB-1, TONE VOLUME 8.3x3.5 DIA .5 M
M
HWF118335-6050
1 PVC PLATE BFP211001-0001
20 SCREW CNTL PCB TO CNTL PANEL-3,REAR PLT TO T3.0xL8xP1.06mm HSP140054-3080
18 SCREW POWER PCB TO IC-3, T3.0xL10xP1.06mm HST140054-3100
4 NUT X'FORMER TO REAR PLT-4 M4.0xOD7.0xT3.0mm HNT140700-1300
4 SCREW X'FORMER TO H/SINK-4 M4.0xP0.7xL20 mm HSD143103-3200
2 SCREW SW ROCKER TO JACK PLT ;M3.0xP0.5xL14mm HSP143083-3140
4 SCREW TNFOIL PLT & WOOD BOX-4 T3xL22xP1.06mm HST140051-3220
12 SCREW REAR PLT TO WOOD BOX-12. T4xL20xP1.59mm HSP140091-3200
1 CNTL PANEL METALIC LIGHT GREY SILVER BPF005056-0AY1
1 PCB COVER A ABS LIGHT GREY BPC200001-0001
1 PCB COVER B ABS LIGHT GREY BPC210001-0001
1 SPONGE A EVA JACK ASS'Y-1 IVE200003-0001
2 SPONGE B EVA COVER-A,COVER-B IVE200004-0001
1 SPONGE FIBER FOR HEAT SINK T0.5mm 268x120mm ICH209001-0001
4 SPACER PINGOOD SRS3-8 DSS100020-0002
1 TUBE SHKNG DIA30xL70xT0.4mm UL BLACK TO POWER SW DTB130000-0700
1 TUBE SHKNG DIA=20 L=50 T=0.4 UL POWER SW TO POWER FUSE HOLDR DTB020000-0500
2 AC CONNTOR AC CONNTECOR (HW-C3) COT010002-0001
5 WIRE TIE GT-90M 90mm DWT000001-0900
1 SPONGE OD165xID143xT1.0mm FOR WOOD Box IVE200001-0001
1 REAR PANEL SECC T=2.0mm CEDCOATTING BLK GSE200008-0001
1 RUBBER BUSHING BLACK W/UL BRB200001-0001
1 FUSE HOLDR FUSE HOLDER FH-B02 TO FUSE CFC021001-1001
2 SLEEVING OD2xID1xL18mm DSL001002-0180
1 HEAT SINK AL W238xH32mm W/ANODIZING BLK GAL200003-0001
3 SI RUBBER W13xH18xT0.3 mm FOR IC902 HIS000001-0001
1 BEAD FERIT OD25.0xID15xH12.0 ADD TO POWER WIRE SFB001001-0060
4 WASHER OD6xID3xH2.5mm 602S-V0 FOR IC DHU201001-0001
4 SCREW T3xL6xP1.06mm AMP PCB BKT TO AMP PCB-4. HST140054-3060
2 SCREW T3.5xL8xP1.41mm AMP PCB BKT TO HEAT SINK-2. HSP140074-3080
4 MICA SHEET;L22xW26xT0.1mm (IC421 IC501 IC502 IC703)-1. HIM000001-0007
1 L-EXTRUSION AL W/ANODIZING BLK GAL200004-0001
4 SCREW T3.0xL10xP1.06mm FOR IC421 IC501 IC502 IC703-4. HSP140054-3100
1 GSB BKT R SECC T=1.0mm DC PCB GSE200010-0001
1 PCB BKT L SECC T=1.0mm DC PCB GSE200011-0001
1 FUSE LABEL T 2A 250V YLB003000-0004
