JBL ESC 360 Service Manual

IC901 1 IC 3 PIN 7815 15V 1A RHI007815-0001
IC902 1 IC 3 PIN AN7915T SAMSUNG RHI007915-0001
Q906 1 XISTR PNP 2SA733Q,P NEC RAP200733-0001
D913 1 DIODE 1N4002 1A 70VRMS RAD114002-0010
BD904 1 BRIDGE RECTIFIER;RS402L 4A 100V UL RHD204010-0010
BD901 1 BRIDGE KBU808 8A 800V UL RHD208080-0010
BD902 BD903 2 BRIDGE RS202L 2A 100V UL RHD202010-0010
ZD901 1 DIODE ZENR 4.7-4.9V 0.5W RAZ005005-0020
CN101 1 CONNECTOR B3B-XH-A 3 PIN CCN250000-0103
CN906 1 CONNECTOR B9B-XH-A 9 PIN CCN250000-0109
CN902 1 CONNECTOR 2 PIN LEOCO 3951 CCN396020-0102
CN904 1 CONNECTOR 4 PIN CL3962WVO CCN396020-0104
CN905 1 CONNECTOR 5 PIN CL3962WVO CCN396020-0105
CN901 1 CONNECTOR 6 PIN CL3962WVO CCN396020-0106
CN903 1 CONNECTOR 3 PIN CL3962WVO CCN396020-0103
F901 F902 F903 F904 F905 F906 F907 14 FUSE CLIP DIA5xL20mm FUSE CFC011000-1001
C919 1 COND ELECT 2200 uF 25V 20% 85`C PVE039550-2220
C913 C914 2 COND ELECT 2200 uF 35V 20% PVE039560-2220
C906 C908 2 COND ELECT 4700 uF 50V 20% PVE039570-4720
C939 C940 2 COND ELECT 3300 uF 50V 20% PVE039570-3320
R913 1 RESISTOR 10K OHM 1/6W 5% CF QAF065000-1030
R910 1 RESISTOR 3.3K OHM 1/6W 5% CF QAF065000-3320
R911 1 RESISTOR 4.7K OHM 1/6W 5% CF QAF065000-4720
R912 1 RESISTOR 47K OHM 1/6W 5% CF QAF065000-4730
C920 C922 C924 C925 C927 C933 6 COND DISC 0.1 uF 50V +80-20% PRD339670-1040
C901 C902 C903 C904 17 COND DISC 0.022 uF 50V +80-20% PRD249670-2230
C909 C910 C911 C912
C915 C916 C917 C918
C934 C935 C936 C937 C938
C932 1 COND ELECT 100uF 16V 20% PRE039540-1010
C921 1 COND ELECT 22 uF 25V 20% PRE039550-2200
C923 C926 2 COND ELECT 220uF 25V 20% PRE039550-2210
F903 F904 2 FUSE 1.6A 250V SLOW 5x20mm UL/CSA/T-MARK KSA020160-0010
F901 F902 2 FUSE 8A 250V SLOW KSA020800-0130
Main 1 FUSE ;4A 250V SLOW 5ST BEL KSA020400-0110
F906 F907 2 FUSE ;4A 250V SLOW 5ST BEL KSA020400-0110
F905 1 FUSH 2A 250V SLOW BLOW RUL/VDE/CSA5x20mm KSA020200-0120
2 SLEEVING FOR BD903 BD902 OD2xID1xL15mm DSL001002-0150
7 WASHER FOR POWER PCB OD6xID3xH2.5mm 602S-V0 DHU201001-0001
1 WIRE BARE 22 GA TINNED JP200 TO JP217 XJP220000-0001
4 SCREW DC PCB BKT TO PCB-4. T3.0xL6xP1.06mm HSP140054-3060
Installation Point Qty. Description Material No.
1 SPK JACK ASSY HI APE200064-4001
RB503 1 CON/WIRE 4P 220mm 1007#18 A=3.96VH VWA310006-0008
RB501 1 CON/WIRE 6P 220mm 1007#18 AWG A=3.96VH VWA310006-0010
L401 L501 L502 L601 L602 5 RF COIL 1 uH MDEC T40818-08 SIL001003-1090
JK501 1 TERMINAL IACK ASSY 5 SLOT ABS BLK COT080005-0001
C631 C632 C417 C509 C510 5 COND MYLAR 0.1 uF 100V 5% PRM0373A0-1040
C518 C519 C520 C521 C522 5 COND DISC 0.022 uF 50V +80-20% PRD249670-2230
R423 R513 R514 R643 R644 5 RESISTOR 4.7 OHM 1/2W 5% CF QAF025000-4790
Installation Point Qty. Description Material No.
1 CNTL PCB ASSY (HI) APE200140-4001
RB203 1 CON/WIRE 7P 300mm 1095#28 A=2mm B=2012V VWA200041-0002
RB201 1 CON/WIRE AY 10 COND 320mm P=2.0mm VWA200041-0003
RB202 1 CON/WIRE 8P 320mm 1095#28 A=2mm VWA200041-0004
RB204 1 CON/WIRE 5P 300mm 1095#28 A=2mm B=2512V VWA200041-0005
LD203 LD226 LD228 LD229 LD230 LD231 17 LED Green KED500042-0010
LD232 LD233 LD236 LD237 LD238 LD239
LD240 LD241 LD242 LD243 LD227
LD204 LD205 LD206 LD207 LD210 LD211 22 LED Red KED500525-0010
LD212 LD214 LD215 LD216 LD217 LD218
LD219 LD220 LD221 LD222 LD223 LD224
LD225 LD234 LD235 LD244
LD201 LD202 LD208 LD209 4 LED; 2x5mm RED HI-LIGHT St-by , Mute KED200052-0030
R245 1 RESISTOR 1.2K OHM 1/6W 5% CF QAF065000-1220
Jack pcb
Control pcb
