Dolby Pro-Logic
Ò
Surround Processor/Amplifier ESC200
TABLE OF CONTENTS
ESC200 SPECIFICATIONS ...........................................1
CONTROLS AND THEIR FUNCTION...........................3
ESC200 SPEAKER AND SOURCE CONNECTIONS ..3
ESC200 PACKING.........................................................4
ESC200 BLOCK DIAGRAM...........................................5
ESC200 UNIT EXPLODED VIEW .................................6
ESC200 PARTS LISTS..................................................7
ESC200 KEYPAD PCB................................................10
ESC200 MAIN PCB (Component Side) ......................11
ESC200 MAIN PCB (Solder Side)...............................12
INTEGRATED CIRCUIT DIAGRAMS ..........................13
SCHEMATIC DIAGRAMS ............................................16
ESC200 IC VOLTAGE READINGS.............................23
ESC200 SPECIFICATIONS
Satellite Speaker Subwoofer
Power Handling (RMS) .........20Watts ..........60Watts
Frequency Response ..........120Hz - 20kHz .......35Hz - 200Hz
Sensitivity (1 Watt/1 meter) .......87dB............90dB
Nominal Impedance...........8ohms...........6ohms
Woofer Size ..............3".............6-1/2"
Tweeter Size..............1"
Dimensions (HxWxD) ..........4-1/16 x 7-1/2 x 7-3/8" ....7-3/4 x 13-7/8 x 17-3/4"
103 x 190 x 187mm 198 x 354 x 451mm
Processor Amplifier
Total Maximum Amplifier Output - 100 Watts
Dimensions (HxWxD) - 2-11/16 x13-1/2 x 9" (69 x 343 x 230mm)
Occasional refinements may be made to existing products without notice, but will always meet
or exceed original specifications unless otherwise stated.
