JBL ESC200 Service Manual

7
Dolby Pro-Logic
Ò
Surround Processor/Amplifier ESC200
ESC200 PARTS LISTS
Ref. # Part # Description Qty
MAIN-PCB SECTION
Capacitors
C1, 2, 35, 60, 1-12010PI 1µF E.CAP, 50V+-20% 5x11 7
86, 158, 179
C3 1-12310KI 1000µF 10V+-20% 8x16 1
C5, 199, 202, 205 1-11447RH 0.0047µF 100V+-10% MINI 7
208, 211, 214
C6, 11, 21, 24, 25 1-11122RH 0.22µF 100V+-10%MINI 10
97, 102, 118, 126,
154
C7, 48, 73, 77, 1-11322RH 0.022µF 100V+-10% MINI 7
144, 153, 165
C8, C27, C31, C54, 1-11347RH 0.047µF 100V+-10% MINI 5
C55
C9, 41, 43, 61, 1-14091PI 0.1µF MONO CAP 50V +-20% 7
104, 178, 180 HB-TYPE
C10, 12 1-12122LI 22µF 16V+-20% 5x11 2
C11, 39, 44, 45 1-12110LI 10µF 16V+-20% 5x11 26
47, 62, 64, 66,
69, 70, 72, 88,
89, 94, 98, 99,
103, 107, 115,
123, 137, 140,
161, 162, 164,
171
C13, 14, 16, 17 1-11101RH 0.1µF M.CAP, 100V+-10% MINI 33
20, 32, 33, 40,
53, 57, 80, 81,
82, 83, 84, 92,
93, 105, 106,
113, 114, 121,
122, 129, 130,
150, 156, 182,
183, 184, 185,
219, 220
C15, 67, 75, 79, 1-12020PI 2.2µF 50V+-20% 5x11 20
95, 96, 100, 108,
111, 116, 117,
124, 125, 132, 136,
138, 147, 160, 167,
169
C18, 19, 37, 38, 1-12047PI 4.7µF 50V+-20% 5x11 5
101
C22 1-12968PI 0.68µF 50V+-20% 5x11 LL 1
C23, 58, 87 1-16147PH 470ρF 50V+-10% 3
C26 1-11439RH 0.0039µF 100V+-10% MINI 1
C28, 42 1-12220KI 220µF 10V+-20% 6x11 2
C29, 154, 155 1-11456RH 0.0056µF 100V+-10% MINI 3
C30 1-12002PI 0.22µF 50V+-20% 5x11 1
C36, 145 1-16168PH 680ρF 50V+-10% 2
C49, 74, 78, 152, 1-11433RH 0.0033µF 100V+-10% MINI 6
157, 166
C50, 51 1-16031PH 30ρF C.CAP, 50V+-10% NPO 2
C52, 63, 141, 142, 1-12247KI 470µF 10V+-20% 8x12 5
146
Ref. # Part # Description Qty
C56 1-12147LI 47µF 16V+-20% 5x11 1
C59, 143 1-12210KI 100µF 10V+-20% 5x11 2
C63, 141 1-12247MI 470µF 25V+-20% 8x16 2
C90, 91 1-16110PH 100ρF 50V+- 10% 2
C109, 119, 120, 1-12133NI 33µF 35V+-20% 6x11 6
127, 128, 133
C139, 148, 149, 172 1-12524MI 2200µF 25V+-20% 16x26 85C 4
C177, 186, 187, 188, 1-11201RH 0.01µF 100V+-10% MINI 7
189, 190, 197
C181 1-12922PI 22µF 50V+-20% 5x11 LL 1
C191, 192, 193, 194, 1-16115PH 150ρF 50V +-10% CERAMIC 5
195
C198, 201, 204, 207, 1-16122PH 220ρF 50V +-10% CERAMIC 6
210, 213
C200, 203, 206, 209 1-16301PH 0.001µF 50V +-10% CERAMIC 7
212, 215, 216
C221 1-16010PH 10ρF 50V +-10% CERAMIC 1
Diodes
D1, 2, 3, 4 1-05-031 DIODE 6A1-4 4
D5 1-05-009 DIODE 1N4148 T/R 1
Z1, 2 1-06-001 ZENER 1/2W+-5% 5.1V T/R 2
Z3 1-06-003 ZENER, 1/2W+-5% 8.2V T/R 1
Integrated Circuits
U1 1-09-058 IC, NJM2177AL, DOLBY PRO-LOGIC 1
SURROUND DECODER
U2 1-09-057 NJU9701D/NJU9702D 1
DIGITAL DELAY
U3 1-09-305 CD 4066D QUAD BILATERAL 1
SWITCH
U4 1-09-024 BA14741 ROHM QUAD OP AMP 1
U5, 10, 11, 12 1-09-421 BA4560/4560D ROHM/NJRC 4
DUAL OP AMP
U6, 7, 8 1-09-054 LC7538NM SANYO, ELECTRONIC 3
VOLUME CONTROL
U9 1-09-053 LC7821N SANYO, ANALOG SWITCH 1
U13, 14, 15 1-09-092 LM1876TF NS, 20W POWER AMP 3
U16 1-08-006 REG, NJM7809FA/7809A 1
+9V REGULATOR
U17 1-08-158 REG, NJM7805FA/7805A 1
+5V REGULATOR
Resistors
R1, 2, 23, 27, 30, 1-17-415 1/8W+-5% PS 15K OHM T/B 9
46, 47, 77, 79
R3, 4, 9, 10, 29, 1-17-482 1/8W+-5% PS 100K OHM T/B 12
35, 96, 104, 105,
120, 121, 122
R5, 6, 12, 25, 39, 54, 1-17-410 1/8W+-5% PS 10K OHM T/B 22
57, 67, 80, 90, 108,
109, 111, 113, 123,
124, 125, 126, 164,
165, 166, 170
