JBL escXcite System User Manual

ENGLISH
-2-
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Handle the Power Cord Gently
• To disconnect the plug from the AC outlet, pull on the plug itself,
not on the cord. Pulling the cord may break the wire.
• Disconnect the plug from the AC outlet whenever the unit is to be
left unused for an extended period of time.
• Do not place furniture or other heavy objects on the cord, and
avoid dropping heavy objects on it. Also, do not make a knot
in the cord; this can damage it and cause a fire hazard.
The lightning flash with arrowhead
symbol, within an equalateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products described in this
owner’s manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
EN 55013:2001
EN 55020:2002
EN 61000-3-2:2000
EN 61000-3-3:1995+A1:2001
EN 60065:2002
Gary Mardell
Harman Consumer Group International
Chateau-du-Loir, France 06/04
DESIGN GOAL: Bring the thrill of live performance and movie sound
to
the home environment by calling on JBL’s professional engineering leadership.
SATELLITE TYPE: Titanium-laminate-dome tweeter,
sealed enclosure
SUBWOOFER TYPE: Bass-reflex enclosure
PORT DESIGN: FreeFlow
™
flared
PROFESSIONAL REFERENCE:Cinema Loudspeaker Series
OWNER’S GUIDE
PRODUCT LINE:
MODEL:
escXcite system
SURROUND CINEMA
SPEAKERS
© 2004 Harman International Industries, Incorporated
JBL is a registered trademark of
Harman International Industries, Incorporated.
Part No.
YOM400108-0001
PRO SOUND
COMES HOME
™
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
Europe: 2. Route de Tours, 72500 Château du Loir, France
www.jbl.com

JBL escXcite System Specifications

Power

satellites power output	25 Watts x 5 @ 1% THD
subwoofer power output	60 Watts x 1 @ 1% THD

Audio Performance

signal-to-noise ratio	80 dBA
frequency response	35Hz – 20kHz

Input Specifications

input impedance	20k Ohms
input sensitivity	400mV
auto turn-on sensitivity	2mV

Weight and Dimensions

satellites dimensions	111 x 80 x 92mm
subwoofer dimensions	315 x 300 x 310mm
