JBL escXcite System User Manual

ENGLISH
-4-
• Complete, self-powered DTS,
Dolby* Digital surround
processor with four satellite
speakers, a center channel
loudspeaker, subwoofer,
remote control, and all ampli-
fication built-in.
(Just Add TV!)
• Dolby Digital, DTS, Dolby Pro
Logic*, including Phantom
and 3-Stereo, and Stereo
listening modes.
• Automatic Turn-On and Turn-
Off.
• Automatic Source Switching
for the digital inputs.
• Two digital (one optical and
one coaxial) inputs and two
analog inputs.
• 2-Way video-shielded micro-
satellites with titanium-lami-
nate tweeters and common
voicing for all five channels,
and a 6.5", long-throw, floor-
firing subwoofer.
• Late Night compression for
nighttime listening without
unexpected and objectionably
loud passages.
• All amplification and controls
are mounted in the sub-
woofer, eliminating the need
for a separate control unit.
• Remote controllable via out-
board remote eye that can be
mounted with the center
channel or separately, so that
the subwoofer can be hidden
away.
Features
4 satellites and a center channel
loudspeaker.
Wall-mount brackets.
“Smart” powered
subwoofer/controller.
Included
JBL ” error-free“ speaker cables.
Foot for horizontal placement of
center speaker. Versatile remote
sensor and double-sided tape
provided.
Remote control.
Bass
Treble
Delay Level
0 dB Test
Adjustment
Late Night
Power
Mute
Surround
Mode
Input
–
+
–
+
–
+
Volume
Digital coax input cable and
analog RCA input cable.

JBL escXcite System Specifications

Power

satellites power output	25 Watts x 5 @ 1% THD
subwoofer power output	60 Watts x 1 @ 1% THD

Audio Performance

signal-to-noise ratio	80 dBA
frequency response	35Hz – 20kHz

Input Specifications

input impedance	20k Ohms
input sensitivity	400mV
auto turn-on sensitivity	2mV

Weight and Dimensions

satellites dimensions	111 x 80 x 92mm
subwoofer dimensions	315 x 300 x 310mm
