JBL escXcite System User Manual

ENGLISH
-6-
On shelves.
On the wall.
Mounting Options
On optional Stand (FS1000)
Subwoofer
Surround Speakers
5
– 6 ft.
Front and Surrounds Speakers
one. Speaker Placement
Satellites
0-2 ft.
Mounting Remote Sensor to Center Speaker.
Place remote sensor at bottom
of center speaker.
Insert support leg through
remote sensor and into
speaker.
Center speaker.
The remote sensor may be placed anywhere using the supplied double-sided tape.

JBL escXcite System Specifications

Power

satellites power output	25 Watts x 5 @ 1% THD
subwoofer power output	60 Watts x 1 @ 1% THD

Audio Performance

signal-to-noise ratio	80 dBA
frequency response	35Hz – 20kHz

Input Specifications

input impedance	20k Ohms
input sensitivity	400mV
auto turn-on sensitivity	2mV

Weight and Dimensions

satellites dimensions	111 x 80 x 92mm
subwoofer dimensions	315 x 300 x 310mm
