JBL HT PS300 User Manual

If there is no output from
the subwoofer, check the
following:
• System is on and a source
is playing.
• The HT PS300 is plugged in
and “Power” is on.
• If you are using the
THX input, make sure the
THX/ Normal switch is set
to “THX.”
• If you are not using the
THX input, make sure the
THX/ Normal switch is set
to “Normal.”
• If you are using the “High
Level Inputs,” check all wires
and connections between the
receiver/amplifier and the
subwoofer. Make sure all wires
are connected and that none
of the speaker wires are
frayed, cut, or punctured.
• Adjust the “Output Level”
control.
• Review proper operation of
your receiver/amplifier.
If there is low bass output,
check the following:
• Make sure that the sub-
woofer is plugged into a live
electrical outlet and the
“Power” is on.
• If you are using the “High
Level Inputs,” make sure the
connections to the left and
right “High Level Inputs”
have the correct polarity
(+ and –).
• Adjust the “Crossover
Frequency.”
• Adjust the “Output Level”
control.
• Change the setting on the
“Phase” switch.
If you are hearing midrange
frequencies (such as voices)
through the subwoofer,
check the following:
• When using the THX mode,
make sure the subwoofer
crossover is activated on your
processor/receiver.
• When using the “Line
Level” or “High Level Inputs,”
adjust the “Crossover
Frequency” to a lower
frequency.
Troubleshooting
HT PS 300 (120V) OM 7/22/98 2:05 PM Page 7

JBL HT PS300 Specifications

Power

amplifier power	200 watts

Drivers

driver size	12 inches
driver material	polymer-laminated cones

Inputs and Outputs

inputs	THX and normal line level, high level
outputs	high level

Frequency and Response

crossover frequency	50Hz – 120Hz
frequency response	25Hz – crossover point

Weight and Dimensions

dimensions	552 x 533 x 533 mm
weight	67 lbs/30.5 kg
