Fuses
F901, F902 (DC PCB) KSA2800-001 FUSE 8A 250V 2
F903, F904 (DC PCB) KSA2160-003 FUSE 1.6A 250V 5x20 mm 2
W/UL. CSA. T MARKING
F905 (DC PCB) KSA2100-002 FUSE 1A 250V 5x20 mm 1
W/UL. CSA. T MARKING
F906, F907 KSA2400-104 FUSE 4A 250V SLOW 5ST BEL 2
(PWR PCB) 5x20mm CSA/UR/VDE/SE
APE0214-003 DECODER PCB ASSY
Connectors
CN601A CCN7879-031 CONNECTOR J.S.T. 2.0 mm PH 1
B11B-PH-K TOP SIZE
CN602A CCN2032-L15 CONNECTOR TUC-P15X-B1 1
PITCH=2.0 mm SIDE
CN603A CCN2032-L07 CONNECTOR TUC-P7X-B1 1
PITCH=2.0 mm SIDE
Capacitors
C635, C636, C637, PRE3953-101 COND ELECT 100uF 25V 20% 85’C 4
C638
C639, C640 PRM3737-682 COND MYLAR 0.0068uF 100V 5% 2
C641, C642, C643, PRE3951-470 COND ELECT 47uF 10V 20% 85’C 4
C644
C645 PRE3951-100 COND ELECT 10uF 10V 20% 85’C 1
C646, C648, C670 PMA3955-109 COND ELECT 1uF 50V 20% 3
P=2.5 mm AI (MINI)
C647, C657, C658, PCW3965-104 CHIP CAP 0.1uF 50V +80-20% 18
C659, C660, C661, TYPE Y5V
C662, C663, C664,
C665, C666, C667,
C668, C671, C839,
C840, C841, C843
C649, C651, C652, PMA3951-479 COND ELECT 4.7uF 10V 20% 6
C653, C654, C790 P=2.5 mm AI (MINI)
C672, C673 PCW1035-300 CHIP CAP 30pF 50V 5% 2
TYPE NPO
C674 PRM3737-473 COND MYLAR 0.047uF 100V 5% 1
C675 PRM3737-103 COND MYLAR 0.01uF 100V 5% 1
C676 PEP2636-104 COND MPEM 0.1uF 63V 5% 1
MINI SIZE (AI)
C677, C691, C738, PRE3953-101 COND ELECT 100uF 25V 20% 85’C 7
C789, C795, C809
C811
C678, C679, C682, PCW5635-682 CHIP CAP 0.0068uF 50V 5% 12
C683, C688, C692,
C693, C696, C697,
C700, C701, C803
C680, C684, C689, PEP2636-474 COND MPEM 0.47uF 63V 5% 6
C694, C698, C702 MINI SIZE (AI)
C681, C685, C690, PCW1035-561 CHIP CAP 560pF 50V 5% 6
C695, C699, C703 TYPE NPO
C686, C728, C734, PMA3951-470 COND ELECT 47uF 10V 20% 16
C748, C752, C753, P=2.5 mm AI (MINI)
C755, C757, C766,
C767, C783, C784,
C786, C787, C788,
C829
C704, C705, C706, PMA3951-101 COND ELECT 100uF 10V 20% 10
C713, C715, C716, P=2.5 mm AI (MINI)
C717, C726, C765,
C785,
C720, C724, C736, PMA3953-101 COND ELECT 100uF 25V 20% 13
C750, C754, C798, P=2.5 mm AI H=7mm
C799, C800, C801,
C810, C812, C815,
C816
C723, C729, C730, PCW1035-331 CHIP CAP 330pF 50V 5% 6
C741, C744, C756 TYPE NPO
C758 PCW1035-220 CHIP CAP 22pF 50V 5% 1
TYPE NPO
C759, C832, C880, PRD3545-104 COND DISC 0.1uF 50V 10% Y5P 4
C882
C760 PMA3952-220 COND ELECT 22uF 16V 20% 1
P=2.5 mm AI (MINI)
C761 PRM3737-152 COND MYLAR 0.0015uF 100V 5% 1
C762 PRM3737-153 COND MYLAR 0.015uF 100V 5% 1
C764 PRE3951-101 COND ELECT 100uF 10V 20% 85’C 1
C768, C778, C779 PMA3952-101 COND ELECT 100uF 16V 20% 3
P=2.5 mm AI (MNI)
C769, C773, C777, PCW1035-470 CHIP CAP 47pF 50V 5% 12
C780, C781, C782, TYPE NPO
C834, C835, C836,
C837, C838, C842
C770, C776 PEP2636-824 COND MPEM 0.82uF 63V 5% 2
MINI SIZE (AI)
C771, C775 PRM3737-562 COND MYLAR 0.0056uF 100V 5% 2
C772, C774 PRM3737-472 COND MYLAR 0.0047uF 100V 5% 2
C813, C814 PMA3955-339 COND ELECT 3.3uF 50V 20% 2
P=2.5 mm AI (MINI)
C830, C831 PVE3951-102 COND ELECT 1000uF 10V 20% HI 2
C833 PCW5635-223 CHIP CAP 0.022uF 50V 5% 1
TYPE X7R
C881 PCW1035-101 CHIP CAP 100pF 50V 5% 1
TYPE NP
C883 PMA3955-479 COND ELECT 4.7uF 50V 20% 1
P=2.5 mm AI (MINI)
C887 PCW3955-104 CHIP CAP 0.1uF 50V 20% 1
TYPE Y5V
C888 PRD1335-390 COND DISC 39pF 50V 5% NPO 1
Diodes
D601 RCD4148-001 DIODE SW LL4148 TELEFUNKEN 1
SMT TYPE
D602 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS 1
ZD601, ZD602 RAZ0859-073 DIODE ZENR 6.9-7.2V 0.5W 2
HITACHI HZ7B-2
Integrated Circuits
IC601 RCI3861-001 IC 100 PIN ZR38601 ZORAN 1
AC3 DECODER
IC605,IC606,IC608, RCI0720-001 IC 8 PIN TL072 SMT TYPE 11
IC609,IC610, DUAL OP-AMP
IC611,IC612,
IC613, IC621,
IC622, IC623
IC607 RCI1117-001 IC 3 PIN REG1117 3.3V 1
12
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
