Integrated Circuits
IC201 RCI8747-041 IC 44 PIN TC9819 1
8 BIT MICROCONTROLLER
IC202, IC203, IC204 RHI4094-001 IC 16 PIN TC4094BP TOSHIBA 3
8 BIT SHIFT REGISTER
IC301 RHI4052-001 IC 16 PIN TC4052BP DIP 1
4 CH MULTIPLEXER
IC302, IC303, IC304, RHI0740-001 IC 14 PIN TL074CN QUAD OP-AMP 7
IC401, IC601,
IC602, IC702
IC501 RHI0407-250 IC 20 PIN STK407-250 POWER IC 1
IC701 RHI5218-002 IC 8 PIN M5218AL MITSUBISHI 1
OP AMP L TYPE
Resistors
R101, R103, R106, QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF 40
R108, R113, R118,
R119, R120, R214,
R229, R230, R237,
R251, R252, R253,
R254, R255, R256,
R257, R258, R259,
R261, R263, R265,
R267, R269, R271,
R273, R275, R277,
R279, R283, R285,
R287, R289, R290,
R291, R292, R311,
R312
R102, R107, R321, QAF0650-105 RESISTOR 1.0M OHM 1/6W 5% CF 6
R322, R378, R379
R104, R109, R110, QAF0650-151 RESISTOR 150 OHM 1/6W 5% CF 5
R211, R327
R105, R112, R225, QAF0650-473 RESISTOR 47K OHM 1/6W 5% CF 9
R238, R239, R526,
R528, R531, R533
R116, R201, R202, QAF0650-472 RESISTOR 4.7K OHM 1/6W 5% CF 38
R203, R204, R205,
R206, R207, R208,
R209, R212, R213,
R215, R216, R217,
R218, R219, R220,
R221, R223, R224,
R226, R227, R228,
R231, R236, R323,
R324, R365, R366,
R414, R532, R534,
R544, R627, R628,
R725, R737
R117, R288, R309, QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF 13
R310, R313, R314,
R331, R373, R374,
R416, R501, R502,
R729
R210, R315, R316, QAF0650-332 RESISTOR 3.3K OHM 1/6W 5% CF 4
R701
R232, R317, R318, QAF0650-101 RESISTOR 100 OHM 1/6W 5% CF 7
R369, R370, R735,
R736
R240, R355, R356, QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF 20
R357, R358, R380,
R410, R411, R417,
R420, R427, R503,
R504, R521, R522,
R527, R619, R620,
R621, R622
R247, R381, R382 QAF0650-471 RESISTOR 470 OHM 1/6W 5% CF 3
R248, R249, R260, QAF0650-152 RESISTOR 1.5K OHM 1/6W 5% CF 30
R262, R264, R266,
R268, R270, R272,
R274, R276, R278,
R280, R284, R286
R293, R294, R295,
R296, R297, R298,
R299, R422, R425,
R509, R510, R517,
R518, R539, R540
R301, R302, R303, QAF0650-243 RESISTOR 24K OHM 1/6W 5% CF 14
R304, R305, R306,
R307, R308, R363,
R364, R377, R413,
R625, R626
R329, R334 QAF0650-224 RESISTOR 220K OHM 1/6W 5% CF 2
R332, R525, R732 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF 3
R341, R342, R402, QAF0650-273 RESISTOR 27K OHM 1/6W 5% CF 5
R603, R604
R343, R344, R403, QAF0650-202 RESISTOR 2K OHM 1/6W 5% CF 5
R605, R606
R347, R348, R361, QAF0650-913 RESISTOR 91K OHM 1/6W 5% CF 10
R362, R406, R412,
R609, R610, R623,
R624
R351, R352, R353, QAF0650-203 RESISTOR 20K OHM 1/6W 5% CF 10
R354, R407, R408,
R613, R614, R615,
R616
R359, R360, R409, QAF0650-682 RESISTOR 6.8K OHM 1/6W 5% CF 7
R617, R618, R703,
R705
R367, R368, R415, QAF0650-752 RESISTOR 7.5K OHM 1/6W 5% CF 5
R629, R630
R375, R376 QAF0650-681 RESISTOR 680 OHM 1/6W 5% CF 2
R383, R384 QAF0650-100 RESISTOR 10 OHM 1/6W 5% CF 2
R421, R511, R512 QAF0650-563 RESISTOR 56K OHM 1/6W 5% CF 3
R423, R513, R514 QAF0250-479 RESISTOR 4.7 OHM 1/2W 5% CF 3
R424, R515, R516 QVE3050-228 RESISTOR 0.22 OHM 3W 5% 3
CEMENT FIXED RADIAL
R426, R519, R520, QAF0650-393 RESISTOR 39K OHM 1/6W 5% CF 4
R523
R428, R429 QAF0450-101 RESISTOR 100 OHM 1/4W 5% CF 2
R536, R537 QAF0450-330 RESISTOR 33 OHM 1/4W 5% CF 2
R543, R734 QAF0650-222 RESISTOR 2.2K OHM 1/6W 5% CF 2
R704, R706 QAF0650-153 RESISTOR 15K OHM 1/6W 5% CF 2
R726 QAF0650-362 RESISTOR 3.6K OHM 1/6W 5% CF 1
R727 QAF0650-683 RESISTOR 68K OHM 1/6W 5% CF 1
R731 QAF0650-204 RESISTOR 200K OHM 1/6W 5% CF 1
R733 QAF0650-363 RESISTOR 36K OHM 1/6W 5% CF 1
R738 QAF0650-109 RESISTOR 1 OHM 1/6W 5% CF 1
Transistors
Q101, Q102, Q103, RAN0945-001 XISTR NPN 2SC945P NEC 36
Q104, Q251, Q252,
Q253, Q254, Q255,
Q256, Q257, Q258,
Q259, Q260, Q261,
Q263, Q264, Q267,
Q268, Q269, Q272,
Q273, Q274, Q275,
15
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
