jcb 19C-1E Quick Reference Guide

2
DISCLAIMER
19C-1E
This Quick Reference Guide is to provide quick and simple information to the
Operator and does not include any health and safety aspects. In addition,
because of our continual development of machines, features described in this
Quick Reference Guide may differ from those on your machine. No errors and
omissions can be entirely ruled out.
This Quick Reference Guide DOES NOT replace the Operators Manual. You
MUST read ALL the disclaimers and safety and other instructions in the
Operators Manual before initially operating this product. Accordingly, no legal
claims can be entertained on the basis of the data, illustrations or descriptions
in this Quick Reference Guide.
This machine should not be operated by any person who isn’t appropriately
qualified or had the appropriate training.
Operation of this machine without periodic maintenance could cause it to
malfunction. For more information please contact your JCB Dealer.
WARNING: This machine uses a 48V electrical powertrain system. DO NOT
work on this machine unless you are suitably trained, competent and
authorised to carry out work in a safe and controlled manner.

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
