jcb 30PLUS Quick Start Guide

12 Please see operator manual for full details.
1
4
7
2
5
3
6
9
Insert Isolator Key
Engine Pre Heat
Lower LH Arm Rest
Raise LH Arm Rest
Disarm Immobiliser
Engage Seat Belt
Start Machine
Operate Machine
Insert isolator key (A) and
turn in a clockwise direction.
Turn ignition to position 1 (A)
to pre-heat engine before start.
Wait until pre-heat symbol (B)
on instrument panel goes off.
Lower the LH arm rest to
activate the hydraulics.
All controls are now active
and the machine is now ready
to use.
If fitted, disarm by entering
4-digit PIN code than push
ENT button.
The LED
will come
on for 3
seconds.
From ignition position 1 turn
ignition to position 3 (A) to start
the machine.
Ensure the hydraulic isolation
lever (left hand arm rest) is in
the raised position.
Engage seat belt (A) into latch
(B) before starting machine.
A Handle
B LH arm rest
A Handle
B LH arm rest
A
B
Start Up Sequence
A
A
