8025 ZTS, 8026 CTS, 8030 ZTS, 8035 ZTS 15
1. Park the machine on solid, level ground
I. Release the two track levers
II. Set the hand throttle lever to the idle position
2. Lower the dozer blade (B)
3. Lower the excavator so the attachment is flat on the ground (A)
4. Stop the engine
5. Discharge the hydraulic pressure
6. Isolate the controls and remove ignition key
7. Isolate the battery to prevent accidental operation of the engine
Maintenance Position
Fig 14
A Attachment flat on the ground
B Dozer blade lowered to ground
The double-acting ball valve must be open for single-acting attachments and closed for double-acting attachments.
