About the Product
Description
7 9821/3700-4 7
Main Component Locations
Figure 3.
A
B
E
D
C
A ROPS (Roll-Over Protective Structure)/FOPS
(Falling Object Protective Structure) cab
B Ram
C Loader arms D Shovel
E Engine cover
