jcb 8040ZTS User Manual

Section 1 - General Information
Service Tools
Numerical List
1-15 1-15
9803/9360-3
Service Tools
Numerical List
The tools listed in the table are special tools required for
carrying out the procedures described in this manual.
These tools are available from JCB Service.
Some tools are available as kits or sets, the part numbers
for parts within such kits or sets are not listed here. For full
details of all tools, including the content of kits and sets,
refer to Tool Detail Reference, Section 1.
Note: Tools other than those listed will be required. It is
expected that such general tools will be available in any
well equipped workshop or be available locally from any
good tool supplier.
Part
Number
Description See Section
- Bonded Washers - see Tool Detail Reference (Section 1) for content E
- Female Cone Blanking Plugs - see Tool Detail Reference (Section 1) for content E
- Female Connectors - see Tool Detail Reference (Section 1) for content E
- Hydraulic Flow Test Equipment - see Tool Detail Reference (Section 1) for content E
- Hydraulic Hand Pump Equipment - see Tool Detail Reference (Section 1) for content E
- Male Adapters - BSP x BSP - see Tool Detail Reference (Section 1) for content E
- Male Adapters - BSP x NPT (USA only) - see Tool Detail Reference (Section 1) for
content
E
- Male Cone Blanking Caps - see Tool Detail Reference (Section 1) for content E
- Pressure Test Points - Adaptors - see Tool Detail Reference (Section 1) for content E
- Pressure Test Points - 'T' Adaptors - see Tool Detail Reference (Section 1) for content E
- Rivet Nut Tool - see Tool Detail Reference (Section 1) for content B
331/22966 Pump Drive Alignment Tool E
331/31069 Test Block for A.R.V. E
4104/1310 Hand Cleaner B
892/00039 Spool Clamp E
892/00041 De-glazing Tool K
892/00137 Micro-Bore Hose E
892/00223 Hand Pump E
892/00253 Hydraulic Circuit Pressure Test Kit - see Tool Detail Reference (Section 1) for content E
892/00254 Hose E
892/00271 Adapter E
892/00272 Adapter E
892/00273 Adapter E
892/00274 Adapter E
892/00275 Adapter E
892/00276 Adapter E
