jcb AG2200 User Manual

SO53 3LE
Customer Helpline 0845 600 5526
1. LOCK-OFF & LOCK-ON SWITCH
2. HAND GRIP AREA
3. ANTI-VIBRATION AUXILIARY HANDLE
4. SPINDLE LOCK BUTTON
5. OUTER FLANGE
6. INNER FLANGE
7. SPINDLE
8. DISC *
9. SPANNER
10.PROTECTION GUARD FOR GRINDING
11.CLAMPING SCREW
12.RAISED PROJECTION
13.PROTECTION GUARD FOR CUTTING *
14.INSULATING TIP (See
7
)
15.CARBON BRUSH (See
7
)
16.COMMUTATOR (See
7
)
17.CARBON BRUSH CAP (See
8
)
*
Not all accessories illustrated are included as standard.
COMPONENT LIST
10
13
11
12
2
1
3
4
5 6 7 98

jcb AG2200 Specifications

General

Brand	jcb
Model	AG2200
Category	Grinder
Language	English
