Lowering The Windshield And Removing Side
Bars
1. Lower the fabric top or remove the hard top following
the instructions in this manual.
NOTE: To assist in properly reinstalling side bars, mark
the original locations prior to removing.
2. Remove the two top hex bolts (13 mm), and the one
side hex bolt (13 mm) visible through the trim (Do not
remove plastic corner trim, sun visor bolts, or sport bar
covering).
3. Open sport bar Velcro covering.
4. Remove the one hex bolt (13 mm) visible through the
plastic trim on bottom side of side bar, one hex bolt (13
mm) on the side of the side bar, and one hex bolt (13 mm)
on top of the side bar.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193
3
