102 GETTING TO KNOW YOUR VEHICLE
2. Manually remove the protective caps over
the windshield wiper hex bolts.
Step Two
3. Using the provided 15mm socket, remove
the two hex bolts and remove the wiper
arms.
4. Move to the inside of the vehicle and lower
both sun visors.
5. Using the provided #40 Torx head driver,
remove the four Torx screws located along
the interior of the windshield.
Step Five
NOTE:
Store all of the mounting bolts in their original
threaded holes and tighten for safekeeping.
6. Lower the windshield gently until it contacts
the tie-down bumpers (if equipped).
Step Six
7. Secure the windshield by passing a cinch
strap through the tie-down on either side of
the hood and on the windshield frame.
Tighten the strap to secure the windshield
in place.
1 — Outside Torx Screws
2 — Inside Torx Screws
1 — Washer Nozzle
2 — Bumper
3 — Tie-Down
CAUTION!
Do Not Overtighten! Damage to the wind-
shield could result.
21_JL_OM_EN_USC_t.book Page 102
