GETTING TO KNOW YOUR VEHICLE 85
INSTALLING THE SOFT TOP
1. If currently installed, remove the hard top
Ú
page 91.
2. Install the door rails, starting with the front,
followed by the rear on each side. For
instructions and appropriate torque specifi-
cations for the door rail Torx screws
Ú page 99.
3. Install the rear retainers on each side of the
rear of the vehicle using the provided
#50 Torx head driver and ratchet. Refer to
the table below for recommended torque
specifications.
Step Three
4. Making sure the lift assist mechanism is in
the “lock” position, lift the soft top into the
rear of the vehicle with the side links
pointing toward the front. Lower the lift
assist mechanisms onto its retainers on
both sides (on the inside of the sport bar).
Step Four
Step Four
CAUTION!
Do not over tighten Torx screws. Damage to
the retainers will occur.
Torque Speci-
fication For
Torx Screw
Maximum Minimum
119.5 in-lbs 150.5 in-lbs 106.2 in-lbs
13.5 N·m 17.0 N·m 12.0 N·m
CAUTION!
Failure to follow the next steps could result in
damage to the Soft Top or vehicle.
2
