Preamplifier Rear Panel
A INPUTS 1-5 (Female XLR): Five (5) XLR fully balanced or single-
ended inputs (via supplied XLR/RCA adapters) are provided for line
level signals only. Each INPUT connector conforms to a Pin #1 ground,
Pin #2 negative, Pin # 3 positive standard. Both positive and negative
terminals of each INPUT connector are isolated from ground by several
megohms which eliminates the possibility of ground loops and restores
maximum common mode rejection ratio.
B BYPASS INPUT (Female XLR): Accepts balanced or single-ended inputs
(via supplied XLR/RCA adapters) from home theater surround processor
front left and front right outputs.
C MAIN OUTPUT (male XLR): Provides XLR fully balanced or single-
ended outputs (via supplied XLR/RCA adapters). OUTPUT connector
conforms to a Pin #1 ground, Pin #2 negative, Pin #3 positive standard.
Balanced output signals are always provided regardless of input (single-
ended or balanced) signal configuration.
D REC OUTPUT (male XLR): Provides XLR fully balanced or single-ended
outputs (via supplied XLR/RCA adapters). OUTPUT connector conforms
to a Pin #1 ground, Pin #2 negative, Pin #3 positive standard. REC
OUTPUT is buffered from any selected input. Balanced output signals
are always provided regardless of input (single-ended or balanced) signal
configuration.
E POWER SUPPLY INPUT (male XLR): Interconnects the Preamplifier to
the Power Supply via the supplied DC power cable. Caution: Use only
the supplied DC power cable and companion Power Supply.
Power Supply Rear Panel
1 POWER SUPPLY OUTPUTS A & B (XLR female connectors): Parallel DC
power and signal data outputs for preamplifier and optional companion
units such as phono equalizer, etc.
2 AC POWER INLET: Verify that the voltage indicated on the rear panel
corresponds to the AC mains of your service area.
Preamplifier and Power Supply Rear Panels
