Synergy Performance Specifications
Overall Gain Adjustable for each input ±20 dB relative
to unity gain (0 dB) in 0.5 dB increments
Input Impedance Adjustable for each input
Unbalanced 36k or 600 ohms
Balanced 36k or 600 ohms
Output Impedance
Unbalanced 40 ohms
Balanced 80 ohms
Maximum Input Level 13 volts RMS at 0 dB gain
Maximum Output Level 13 volts RMS (24 dBm)
Output Noise Level 12 microvolts
20-20 KHz bandwidth, 0 dB gain
Signal To Noise Ratio Greater than 96 dB
Channel Separation Greater than 100 dB, 20-20 KHz
bandwidth
Frequency Response 5 Hz-160 KHz, -3 dB
THD + Noise 0.0016% 10 volt output, 600 ohm load
Gain Range 63.5 dB, 127 equal increments
Gain Resolution 0.5 dB ± 0.03 dB over entire range
Channel Balance ± 0.03 dB throughout entire range
Dimensions 17.5 in W x 6.0 in D x 3.15 in H
44.5 cm W x 15.25 cm D x 8.0 cm H
Weight 24 lbs (11 kg)
Power Supply Specifications
Power Consumption 25 watts maximum
Mains Voltage 100V, 120V, 220V, 240V, 50/60 Hz
Dimensions 17.5 in W x 4.8 in D x 1.5 in H
44.5 cm W x 12.2 cm D x 3.8 cm H
Weight 7 lbs (3 kg)
Because Jeff Rowland Design Group is constantly analyzing new
design improvements, we reserve the right to change or modify product
specifications without notice or obligation.
