13
1. Enter image setting mode by pressing the [PIC] Button on the remote control.
2. Select the item to be adjusted and touch the Left or Right direction icons
[ ]/[ ] on the user interface to adjust the value.
3. To exit image setting mode, press the [PIC] Button on the remote control again
or simply stop making adjustments.
Equalizer Controls
Equalizer (EQ): Adjustment can be made after entering one of
the audio/video sources (Disc, Radio, USB, AV-IN1, or AV-IN2)
Touch the Equalizer (EQ) icon to view the Equalizer Control Screen to select a
desired audio preset level ( Pop / Techno / Rock / Classic / Jazz / Optimal or User),
make adjustments to the audio Balance and Fade levels or to turn the Loudness
option ON or OFF. Touch the return icon to return to the current source.
Playing a Disc
To begin playback of an Audio/Video Disc:
1. Press the front panel Power/Volume/Mute control knob to turn the unit ON.
2. Insert a disc with the label side facing UP and playback will begin
automatically.
Parking Brake Inhibit
When the pink “Parking” wire is connected to the vehicle Parking Brake circuit, the
front TFT monitor will display video when the Parking Brake is engaged.
Figure 6. Image Settings Screen
Change Aspect Ratio (DVD / AV In Sources Only)
Press the [WIDE] button on the remote control to adjust the aspect ratio.
Image Settings (DVD / AV In Sources Only)
VX3012
