System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin 69
C450CBN-3C and C450CCN-3C Control Modules with Relay Output
Product C450CBN-3C and C450CCN-3C: System 450 Control Module models are sensing
controls and operating controls with LCD, four-button touchpad, and SPDT relay output
C450CBN-3C: Control Module with one SPDT output relay
C450CCN-3C: Control Module with two SPDT output relays
Power Consumption C450CBN-3C: 0.9 VA maximum
C450CCN-3C: 1.3 VA maximum
Supply Power Internal Supply Power: C450YNN-1C Power Supply Module
External Supply Power: 24 VAC (20–30 VAC) Safety Extra-Low Voltage (SELV)
(Europe), Class 2 (North America), 50/60 Hz, 10 VA minimum; or 22 to 30 VDC
Note: A System 450 control module or module assembly can use an internal or an
external supply power source, but must not be connected to both simultaneously.
Ambient Operating Conditions Temperature: -40 to 66C (-40 to 150F)
Humidity: Up to 95% RH noncondensing; Maximum Dew Point 29C (85F)
Ambient Shipping and Storage
Conditions
Temperature: -40 to 80C (-40 to 176F)
Humidity: Up to 95% RH noncondensing; Maximum Dew Point 29C (85F)
Input Signal 0–5 VDC for humidity sensors and static pressure transducers
0.5–4.5 VDC for ratiometric pressure transducers
1,035 ohm at 25C (77F) for A99 PTC temperature sensors
1,000 ohm at 21.1C (70F) for TE-6xxx Nickel temperature sensors
Output Relay Contacts General: 1/2 HP at 120/240 VAC, SPDT
Specific: AC Motor Ratings 120 VAC 208/240 VAC
AC Full-load Amperes: 9.8 A 4.9 A
Locked-Rotor Amperes: 58.8 A 29.4 A
_____________________________________
10 Amperes AC Non-inductive at 24/240 VAC
Pilot Duty: 125 VA at 24/240 VAC
Analog Input Accuracy Resolution: 14 bit
Control Construction Independently mounted control, surface mounted with Lexan® 950 enclosure suitable for
DIN rail mounting or direct mounting to a hard, even surface.
Dimensions (H x W x D) 127 x 61 x 61 mm (5 x 2-3/8 x 2-3/8 in.)
Weight C450CBN-3C: 209 g (0.46 lb)
C450CCN-3C: 222 g (0.49 lb)
Compliance North America: cULus Listed; UL 60730, File E27734;
FCC Compliant to CFR47, Part 15, Subpart B, Class B;
Industry Canada (IC) Compliant to Canadian ICES-003, Class B limits
Europe: CE Mark – Johnson Controls, Inc. declares that this product is in compliance with
the essential requirements and other relevant provisions of the EMC Directive
and the Low Voltage Directive.
Australia: Mark: C-Tick Compliant (N1813)
