WHAT IS WHAT?
5
2
9
10
6
16
21
23
25
1
3
8
11
15
13
14
7
12
30
17
4
4
4
27
22
18
19
20
1
21
24
29
28
26
31
18
32
33
1. Grass blade 18. Locking nut
2. Grease filler cap 19. Support flange
3. Bevel gear 20. Support cup
4. Cutting attachment guard 21. Drive disc
5. Shaft 22. Trimmer head
6. Handlebar 23. Socket spanner
7. Throttle control 24. Transport guard
8. Stop switch 25. Hex wrench
9. Throttle lock--out 26. Locking pin
10. Harness clamp 27. Harness
11. Cylinder cover 28. Start throttle button
12. Starter handle 29. Adjusting the throttle wire
13. Fuel tank 30. Saw blade
14. Choke control 31. Mounting plate/adapter
15. Primer bulb 32. Support flange
16. Air filter cover 33. Operator’ s manual
17. Handle adjustment
