31
ENGLISH
6.3 Cleaning and soot removal
Soot deposits may build up on the internal surfaces of the
fireplace during use. Soot is a good insulator and will therefore
reduce the fireplace’s heat output. If soot deposits accumulate
when using the product, they can easily be removed by using a
soot remover.
An annual internal cleaning is necessary to get the best heating
effect from your product. It is a good idea to do this when cleaning
the chimney and flue pipes.
6.4 Sweeping flue pipes to the chimney
Flue pipes must be swept through the flue pipe sweeping hatch
or through the door opening.
6.5 Inspection of the fireplace
Jøtul recommends that you carefully inspect your fireplace
yourself after it has been swept/cleaned. Check all visible surfaces
for cracks. Also check that all joints are sealed and that the gaskets
are in the correct position. Any gaskets showing signs of wear or
deformation must be replaced.
Thoroughly clean the gasket grooves, apply ceramic glue
(available from your local Jøtul dealer) and press the gasket well
into place. The joint will dry quickly.
6.6 Exterior maintenance
Painted products may change colour after several years’ usage.
The surface should be cleaned and brushed free of any loose
particles before new paint is applied.
7.0 Servicing
Warning! Any unauthorised changes to the product are illegal!
Only original spare parts may be used!
7.1 Replacing the burn plates, baffle
and exhaust deflector
Fig. 44
1
2
B
A
1. First remove the log retainer (Fig. 13 A) .
2. Remove the side burn plate (A) by lifting it up slightly while
holding the baffle (B) up. Pull the side burn plate out at the
bottom and lift it out.
3. Then lift out the other side burn plate while holding the baffle
up in the same way as for the first side burn plate.
Fig. 45
A
B
1
2
4. First lift the baffle (A) up. Turn the key (B) 90° and then remove
the key. Pull the back edge of the baffle down.
