3
1.0 Regulatory information
The installation of a fireplace must take place in accordance with
each country’s laws and regulations.
All local ordinances, including those that refer to national and
European standards, must be complied with when products are
installed.
The installation can only be taken into use after it has been
checked by a qualified inspector.
A rating plate made of a heat-resistant material is fixed to the
heat shield. This provides information on identification and
documentation of the product.
2.0 Technical data
Material: Cast iron
Finish: Black Paint
Type of fuel: Wood
Max. log length: 50 cm
Smoke outlet: Top or rear-installed smoke
outlet (rotated 45°).
Flue pipe dimension: Ø 150 mm
Weight: Approx. 110 kg
Optional extras: Leg Rack complete, door lock
complete - left, frames, sheet
metal grids, and convection
top plate.
Product dimensions, distances: See fig. 1
Technical data in accordance with EN 13229
Nominal heat output: 7 kW
Efficiency: 77%
CO emissions (13% O2): 0.07%
CO emissions (13% O2): 884 mg/Nm3
OGC emissions (13% O2): 60 mg/Nm3
Dust emissions (13% O2): 14 mg/Nm3
Flue gas temperature: 305°C
Flue gas flow rate: 7,1 g/s
Chimney draught, EN 13229: 12 Pa
Recommended draught
with smoke outlet: 16-18 Pa
Fuel consumption: 2.3 kg/h
Kindling quantity: 1,7 kg
Max. kindling: 3,4 kg each time and 3,8 kg/h
Operation: Intermittent
“Intermittent combustion” here means normal use of a
stove. That is to say, if you want to continue producing
heat, you add more fuel as soon as the previous load of
wood has burnt down to embers.
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number when
contacting your retailer or Jøtul.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC
SP
EN
Serial no.
Table of contents
Installation manual with technical data
1.0 Regulatory information .................................3
2.0 Technical data ................................................3
3.0 Safety ............................................................. 4
4.0 Installation ................................................... 4
5.0 Daily use .......................................................27
6.0 Maintenance ............................................... 29
7.0 Servicing ...................................................... 30
8.0 Optional Extras ............................................32
8.0 Operational problems - troubleshooting....34
9.0 Recycling .......................................................34
10.0 Guarantee terms ..........................................34
ENGLISH
Register your fi replace at jotul.com for a
25-year warranty.
