– 20 –
Refer to the Instruction Manual for each operation panel for how to operate sewing patterns using
other operation panel than the built-in panel of the machine head.
(1) Reverse feed stitching pattern
Reverse feed stitching at sewing start and reverse feed stitching at sewing end can be separately pro-
grammed.
[Setting procedure of the reverse feed stitching]
1) Effective/ineffective of the reverse feed stitching
pattern can be changed over by pressing
switch ❺.
When the reverse feed stitching pattern is en-
abled, LED Ⓙ lights up and the display section
Ⓐ shows the number of reverse feed stitches at
the beginning of sewing and that at the end of
sewing.
Use and switches to change the num-
ber of stitches for the target process (A, B, C or
D). (The number of stitches that can be set is 0 to
15.)
The numbers of stitches for processes A, B, C
and D are displayed on display section Ⓐ from
left to right in the order from A to D.
2) Enable/disable of the reverse feed stitching at
the beginning of sewing is set by pressing
switch ❶.
Ⓐ
Ⓙ
❶
❷
❸
❹
❺
Ⓚ
❻
Ⓞ
❾
❽
❼
A
B
C
B
C
D
(2) Overlapped stitching pattern
Overlapped stitching pattern can be programmed.
A : Number of stitches of normal stitching setting
0 to 15 stitches
B : Number of stitches of reverse stitching setting
0 to 15 stitches
C : Number of stitches of normal stitching setting
0 to 15 stitches
D : Number of times of repetition
0 to 15 times
When process D is set to 5 times, the sewing is repeated
as A → B → C → B → C.
1) Effective/ineffective of the overlapped stitching pattern can be changed over by pressing switch ❻.
When the overlapped stitching pattern is rendered effective, LED Ⓚ lights up.
2) Press and switches to change the number of stitches for target process (A, B, C or D).
Enable/disable of the reverse feed stitching at the end of sewing is set by pressing switch ❷.
Enable/disable of the double reverse feed stitching at the beginning of sewing is set by pressing
switch ❸.
Enable/disable of the double reverse feed stitching at the end of sewing is set by pressing switch ❹.
3. Operating procedure of the sewing pattern
