– 25 –
Parame-
ter code
Parameter function Range/ unit Default Key Description
Parame-
ter code
Parameter function Range/ unit Default Key Description
P29 Bar-Tacking func-
tion Selection
ON / OFF Reserve Invalid,setting by front shortcut key
P30 Setting stitches of
Bar-Tacking
1 to 99 Stitches Reserve Invalid,setting by front shortcut key
P31 Setting turns of
Bar-Tacking
1 to 15 Stitches Reserve Invalid,setting by front shortcut key
P32 Stitch balance for
Bar-Tacking 5
0 to 31 12
① 0→15 The action gradually delay
② 16→31 The action gradually advance
③ The action of 0 delay than 16
P33 Stitch Balance for
Bar-Tacking 6
0 to 31 12
P34 Mode selection for
Constant-Stitch
sewing
A / M M A : One shot to pedal, it will automatic
execute Constant-Stitch
M : Pedal-controlled and motor can stop
arbitrarily
P35 Constant-Stitch
sewing function se-
lection
ON / OFF Reserve Invalid,setting by front shortcut key
P36 Setting stitches for
section P1 of Con-
stant-Stitch Sewing
1 to 250 Stitch-
es
Reserve Invalid,setting by front shortcut key
P37 Wiper function Se-
lection or thread
clamp pressure
setting
0 to –11 1 0 : No Action
1 : Wiper Action
2-11 : Thread Clamp action and the pressure
gradually increased)
P38 Trimmer function
selection
ON / OFF ON ON : Trimmer Valid
OFF : Trimmer Invalid
P39 Presser foot UP /
Down at intermedi-
ate stop
UP / DN DN UP : Presser foot goes up automatically
DN : Presser foot keeps down (Controlled
by heeling pedal)
P40 Presser Foot UP /
Down after trimming
UP / DN DN UP : Presser foot goes up automatically
DN : Presser foot keeps down (Controlled
by heeling pedal)
P41 Display the sewing
nished quantity
0 to 9999 0 Counting the nished-sewing quantity
P42 Sewing speed dis-
play
0 Displaying the current sewing speed (the
speed only for reference)
P43 Setting direction of
motor rotation
CW / CCW CCW CW : Clockwise
CCW : Counter Clockwise (Viewed from
motor shaft side)
To Next Page
