– 58 –

3) Parts List

Removing parts list

Note No. Part No. Name of part Q’ty

1 21332309 Side plate cover 1

2 SS4110815SP Side plate cover setscrew 1

Note No. Part No. Name of part Q’ty

GAKA19010A0 Automatic presser foot lifter (asm.) (1)

1 PA400150100 Automatic presser foot lifter cylinder 1

2 SM6082502TP Cylinder installing screw 4

3 21356506 Cylinder connecting screw 1

4 NM6080001SE Nut 1

5 SD0720331SP Hinge screw 1

6 21356605 Automatic presser foot lifter lever A 1

7 21356803 Automatic presser foot lifter lever B 1

8 SM6051002TP Automatic presser foot lifter lever B setscrew 2

9 21356704 Automatic presser foot lifter lever shaft 1

!0 PJ304065102 Elbow 2

!1 21356308 Automatic presser foot lifter cylinder stay (front) 1

!2 21356407 Automatic presser foot lifter cylinder stay (rear) 1

!3 SS6151040SP Cylinder stay attaching screw 4

!4 CM3002000B1 Caution seal for being caught 1

!5 CM300200001 Caution seal for injury to finger 1

Note No. Part No. Name of part Q’ty Remarks

1 GAKA14020A0 Cord (asm.) 1

2 GAKA14030A0 Solenoid valve (asm.) 1

3 GAK29010000 Quick joint (elbow) 1

4 GAK29015000 Quick joint (straight) 1

5 GAK29016000 Speed controller 1

6 BT0600401EB Air hose 2 1.3 m

7 BT0600401EB Air hose 1 0.18 m

8 HX00123000A Cord presser 1

9 PJ309065202 Quick joint (branch elbow Y) 1

!0 SM4034001SN Solenoid valve setscrew 2

!1 HX002950000 Wire mark 3 1

!2 HX00295000A Wire mark 3 2

Note No. Part No. Name of part Q’ty

1 GAKA14010A0 Pneumatic components (asm.) 1

Note No. Part No. Name of part Q’TY

1 GAKA14040D0 Presser foot lifter knee switch B (asm.) 1

2 SK3514000SC Knee switch (asm.) installing wood screw 2

Removing parts list

Set part No. of automatic presser foot lifter

(Caution : These set part Nos. are the set part Nos. of the parts from List A to List D.)

No. Set part No. Name of set part Q’ty Set contents (List No.) Remarks

ABCD

1 GAKA19010A0 AK119A kit 1 ££ £

2 GAKA19010B0 AK119B kit 1 ££

3 GAKA20010A0 AK120A kit 1 £££

4 GAKA20010B0 AK120B kit 1 ££

* 1 : Part No. 21348552 (automatic reverse feed device set) is necessary as well.

In case of installing automatic reverse feed device

and automatic presser foot lifter after set-up of

machine *1

In case of installing automatic presser foot lifter after

set-up of machine

Kit A (List D)

Pneumatic device components (List C)

Pneumatic device components (List B)

Automatic presser foot lifter components (List A)
