1
–
No. Items Description
1 Model name 2-Needle, 2/3/4-Thread Overlock Sewing Machine (with differential feed
adjusting)
2 Stitch choice 2 needles, 4 thread overlock
2 needles, 3 thread overlock
1 needle, 3 thread overlock
1 needle, 2 thread overlock
3 Sewing speed Up to 1,500 sti/min Rating 1,350±150 sti/min
4 Needle gauge Overlocking: 2.2 mm
5 Overedge width 2 needles, 4 thread: 5.0 to 9.0 mm
1 needle, 3 thread (right hand needle): 3.0 to 7.0 mm
1 needle, 3 thread (left hand needle): 5.0 to 9.0 mm
Roll hemming: 2.0 mm
Knife width 2.5 to 6.5 mm
6 Thread sliding segment (*1) It is in synchronism with the lower knife from scale marks "2.5" to "5" of
the knife adjusting knob.
The amount of travel of the thread sliding segment can be nely adjust-
ed with the MTC knob.
7 Stitch length 1.0 to 4.0 mm (Standard 2.5 mm)
8 Differential feed 1
：
0.7 to 2
9 Needle bar stroke 29.4 mm
10 Presser foot height 4.8 mm to 5.0 mm
11 Feed dog height 1.3 mm (This side end of the sub feed dog P = 2.5 mm; differential feed
ratio: 1:1)
12 Needle system (Japan) ORGAN needle HA×1 # 11 (Standard) to # 14
Needle system (Overseas) SCHMETZ (130/705H 15X1H) # 80
13 Number of needles Max. 2
14 Number of threads to be used Max. 4
15 Needle threader Operated by the manual lever
16 Looper threader Automatic threading by the air pump
17 Air pump Piston pump driven by the motor
Motor: DC 12V
18 Liquid crystal display (*2) Display section: 63.0 mm (W) × 17.5 mm (H)
19 Power switch Rocker switch
20 Light LED 5V x 2
21 Motor 100V : 100 to 120W
110/120V : 100 to 120W
220 to 240V : 100 to 130W
22 Foot control No-heat method (semi-conductor control type)
23 Driving system Timing belt drive
24 Machine size 330 mm (W) × 280 mm (D) × 310 mm (H)
25 Machine weight 9 kg
1
SPECIFICATIONS
M/ML
ML
* 1: Only for ML type
* 2: Only for M/ML types
