Threading (1)
1. Upper looper thread (Blue)
Place the spool on the spool holder pin right under blue marking on
the retractable support rod thread guide.
(1) Bring thread up from the rear of the retractable support rod thread
guide with blue marking.
(2,3) Pass the thread through the thread guide plate.
(4) Bring the thread on to the thread guide.
(5) Lay the thread between the thread tension dial discs.
(6,7,8,9,10,11) Thread the thread guides.
(12) Turn the handwheel until the upper looper is fully raised.
Thread upper looper eye.
(13) Pull about 10 cm of the thread out.
Place the thread under the presser foot, and pull the thread
frombehind the presser foot.
Use a net for a hard twisted thread
When a thread coils around the thread guide due to its hard twist,
cover the spools of upper looper and lower looper with attached nets.
MO-644DN/654DEN
17
