Table 13: CTP2000 4WE&M RTM Pinouts–Connector A (continued)

Connector A

PinSignalSignalPin

33Port 1 MPort 2 SB8

34Port 2 TPort 2 R9

35Port 2 T1Port 2 R110

36Port 2 EPort 2 SG11

37Port 2MPort 2 SB12

38Port 3 TPort 3 R13

39Port 3 T1Port 3 R114

40Port 3 EPort 3 SG15

41Port 3 MPort 3 SB16

50GNDGND25

CTP2000 4WE&M Connector B Pinouts

See Table 14 on page 44 for connector B pinout information. See“CTP2000 4WE&M

Interface Module” on page 14 for signal definitions.

Table 14: CTP2000 4WE&M RTM Pinouts–Connector B

Connector B

PINSignalSignalPIN

26Port 4 TPort 4 R1

27Port 4 T1Port 4 R12

28Port 4 EPort 4 SG3

29Port 4 MPort 4 SB4

30Port 5 TPort 5 R5

31Port 5 T1Port 5 R16

32Port 5 EPort 5 SG7
