CTP Fast Ethernet and Power Cables

•

Fast Ethernet Cables on page 63

•

DC Power Cables on page 63

Fast Ethernet Cables

The Ethernet connection is a standard RJ-45 connector. Typically, a straight-through

cable is used to connect to a switch, and a crossover cable is used to connect to a router.

DC Power Cables

For CTP chassis with DC power options, we recommend 18-AWG power cables.

Chapter 6: Cable and Pinout Specifications
