Table 16: CTP2000 FXO Connector Pinouts on the RTM (continued)

PinSignalSignalPin

32Port 3 RPort 3 T7

34Port 4 RPort 4 T9

36Port 5 RPort 5 T11

38Port 6 RPort 6 T13

40Port 7 RPort 7 T15

42Port 8 RPort 8 T17

44Port 9 RPort 9 T19

46Port 10 RPort 10 T21

48Port 11 RPort 11 T23

Documentation

CTP2000 2W-FXS and 2W-FXO Interface Modules on page 19•

• CTP2000 4WE&M Interface Connector Pinouts on page 43

• CTP2000 Series Console Cable Pinouts on page 58

• CTP Fast Ethernet and Power Cables on page 63

T1/E1 Interface Module Pinouts

Table 17 on page 48 lists the T1/E1 interface module pinouts for the RJ-45 connector.

Table 17: T1/E1 Interface Module—RJ-45 Connector Pinout

SignalRJ-45 Pin

RX Ring1

RX Tip2

–3

TX Ring4

TX Tip5

–6

–7
